| Produkt | Steigung [mm] | Gang pro Zoll | Gewindebereich | D [mm] | |
|---|---|---|---|---|---|
|
9 | - | Tr 55x9 - Tr 60x9 | 25 | |
|
8 | - | Tr 46x8 - Tr 48x8 | 25 | |
|
8 | - | Tr 50x8 - Tr 52x8 | 25 | |
|
5 | - | Tr 44x5 - Tr 48x5 | 25 | |
|
10 | - | Tr 65x10 - Tr 80x10 | 25 | |
|
6 | - | Tr 36x6 - Tr 38x6 | 24 | |
|
4 | - | ≥ Tr 65x4 | 24 | |
|
3 | - | Tr 36x3 - Tr 40x3 | 24 | |
|
7 | - | Tr 38x7 - Tr 42x7 | 22 | |
|
7 | - | Tr 44x7 | 22 | |
|
6 | - | Tr 32x6 - Tr 36x6 | 21 | |
|
6 | - | Tr 30x6 - Tr 32x6 | 16,2 | |
|
6 | - | Tr 34x6 - Tr 42x6 | 16,2 | |
|
5 | - | Tr 24x4 | 15,3 | |
|
5 | - | Tr 26x5 | 15,3 | |
|
5 | - | Tr 28x5 - Tr 36x5 | 15,3 | |
|
3 | - | Tr 24x3 - Tr32x3 | 14 | |
|
4 | - | Tr 20x4 | 12 | |
|
2 | - | Tr 16x2 - Tr 20x2 | 11,7 | |
|
3 | - | Tr 18x3 - Tr20x3 | 11 | |
|
1,5 | - | Tr 14x1,5 | 9,6 | |
|
1,5 | - | Tr 20x1,5, AG ≥ Tr 8x1,5 | 9,6 |
